System

Main Processor

Dual-core embedded processor

Operating System

Embedded LINUX

Video and Audio

IP Camera Input

4 Channel

Audio I/O

1/1, RCA

Two-way Talk

Yes

Display

Interface

1 HDMI, 1 VGA

Resolution

HDMI: 3840×2160,1920×1080,1440×900, 1280×1024 VGA: 1920×1080, 1280×1024, 1280×720

Decoding Capacity

1ch 8MP/4ch 1080P@30fps

Multi-screen Display

1/4

Recording

Compression

H.265 / H.265/H.264 /H.264

Resolution

8MP/6MP/5MP/4MP/3MP/1080P/720P/ D1&etc.

Record Rate

40Mbps

Bit Rate

100Kbps ~ 6Mbps Per Channel

Record Mode

Manual, Schedule (Regular, Continuous), Motion Detection, Video Loss, Camera Tamper, Alarm in

Record Interval

Post-record: 30 ~ 60 sec

Video Detection and Alarm

Trigger Events

Recording, Buzzer, Push message, Pop up message.

Video Detection

Motion Detection, Video Loss, Camera Tamper

Alarm In/Out

4/1

Playback and Backup

Sync Playback

4/1

Search Mode

Time /Date, Alarm, Picture grid, Event

Playback Function

Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Shuffle, Backup Selection, Digital Zoom

Backup Mode

USB Device

Network

Network Function

HTTP, HTTPS, TCP/IP, IPv4, UPnP, UDP, RTSP, SMTP, NTP, DNS, DHCP, P2P, IP Filter, DDNS, 802.1X, SNMP

Max. User

Access  9 users

Smart Phone

iPhone, iPad, Android

Interoperability

ONVIF, SDK, CGI

Storage

Internal HDD

1 SATA Ports, up to 12TB for each HDD

Interface

Interface

1 RJ-45 port (10/100Mbps)

PoE Interface

4ch 100Mbps, IEEE 802.3af

PoE Max Power

40W

USB

2 ports (USB 2.0 x2)

General

Power Supply

DC48V/1.25A

Power Consumption

< 5W (without HDD)

Operating Conditions

14 °F ~ 122 °F (-10 °C ~ 50 °C)

Storage Conditions

Less than 90% RH

Certifications

CE/FCC

Dimensions

10.03” x 9.25” x 1.87 (255×235×47.5mm)

Net Weight

2lb (0.9kg) (No disk)
